 150W DC-DC Boost Converter module allows you to step up an input voltage as low as 10V and set the output voltage to 12V-35V. The output voltage will be higher than the input voltage. The boost converter design is based on popular Texas Instrument’s UC3844 current mode PWM controller chip.
Consider this example; say you want to power your laptop from a car battery, well this module could do that. Or run a 24~35V rated equipment on a single lead 12V lead acid battery.

Technical Specification:

• Input Voltage: 10v – 32v DC
• Output Voltage: 12v – 35v DC
• Output Current: 6A MAX
• Input Current: 10A (MAX)
• Output Ripple: 2% MAX
• Working Temperature: Industrial – 40C to +85C
• Full-Load temperature: 45 degrees.
• No-load current: 25mA typical.
• Voltage regulation: ± 0.5%.
• Load regulation: ± 0.5%.
• Dynamic response speed: 200uS 5%.
• Size: 2.60x1.85x 1.1(L*W*H)

Features:

• The non-isolated step-up power conversion module
• Onboard LED illuminates when the voltage is applied to the module
• Equips Multi-turn Potentiometer.
• Easy to drive 65W 90W dual-core notebook.
• The output voltage is continuously adjustable on OUT+ and OUT- screw terminals (Output voltage must be greater than input voltage)

Pin Description:

Applications:

• High power LED driver.
• Charging the lithium battery (or the lead accumulator).
• Power supply installed in the vehicle.
• Low voltage system power supply.
• 6V 12V 12V 14V battery charge 24V.
• Integrated portable power supply.
• Regulated power supply.
• Low voltage power supply system.
