RM065 1M Ohm Trimpot Trimmer Potentiometer

SKU: 000714D

Quantity: 10 Pcs
Price:
Sale price Rs. 33.90 (excl.18% GST)
Rs. 40.00

Description

A trimmer potentiometer, also known as a trim pot, is a type of variable resistor or adjustable potentiometer that can adjust, tune, and calibrate circuits. These trimmer resistors are often used to initially calibrate equipment after manufacturing. This is 1MΩ variable resistor (RM065 Package), which can be used to set sensitivity and calibrate the circuits.

Technical Specification:

  • Resistance : 1 MΩ
  • Tolerance : 30%
  • Operating Temperature Range : -10°C to 70°C
  • Mounting Type : Through Hole
  • Size : 7mmx6.5mmx5mm (LxWxH)
  • Weight : 0.1gm (approx)

Features:

  • 6mm / Single-Turn / Carbon Film
  • Henolic Base / Resin Mold
  • Open Frame / PC Board Stand-offs
  • Enclosed Cover

Pin Description:



Applications:

  • Comparator circuits
  • Voltage control
  • LED intensity
  • Home appliances
  • Television, video, Mp3, Mp4, VCD, DVD, telephone
  • Office automation equipment,
  • Information communication equipment
