Description
The MPU-6050 is a serious little piece of motion processing tech! By combining a MEMS 3-axis gyroscope and a 3-axis accelerometer on the same silicon die together with an on-board Digital Motion Processor capable of processing complex 9-axis Motion Fusion algorithms, the MPU-6050 does away with the cross-axis alignment problems that can creep up on discrete parts.
Technical Specification:
- Power voltage: 3 - 5V
- Communication mode: I2C / SPI
- Register: 1MHz
- SPI / I2C: 400KHz
- Pitch: 2.54mm
- Size:15mm*25mm (L*W)
Features:
Gyroscope Features:
- Digitally-programmable low-pass filter
- Factory calibrated sensitivity scale factor
Accelerometer Features:
- User-programmable interrupts
- Wake-on-motion interrupt for low power operation of applications processor
Applications:
- Motion-enabled game and application framework
- Location based services, points of interest, and dead reckoning
- Handset and portable gaming
- Motion-based game controllers
