MB27F - 27mm Flat Loud Continuous Buzzer

The MB27F is a high-performance 27mm flat loud continuous buzzer designed for clear and reliable sound output in various electronic applications. This buzzer is ideal for alarms, notifications, and alerts, providing a robust audio signal in a compact form factor.

Technical Specifications

• Minimum Sound Level: 85db
• Oscillation Frequency: 4KHz ± 500Hz
• Current Consumption: Maximum 20mA
• Operating Voltage: 1.5 to 15 VDC
• Weight (gm): 8
• Tone: Loud Continuous
• Mounting: Flange Type
• Wire/Lead Length: 120mm 2 wire
• Height (mm): 13
• Diameter (mm): 31
• Pitch (mm): 36
• Operating Temp Range: 20 to 50°C
• Storage Temp Range: 30 to 60°C


Features

• Loud Sound Output: Delivers a clear and loud alert suitable for various environments
• Continuous Tone: Provides a consistent audio signal for alarms and notifications
• Wide Voltage Range: Operates efficiently within a voltage range of 5V to 12V DC
• Durable Construction: Robust plastic housing ensures longevity and reliability
• Easy Installation: Designed for straightforward PCB mounting

Applications

• Ideal for alarm systems, timers, and notification devices
• Suitable for consumer electronics, home appliances, and automotive applications
• Useful in industrial equipment requiring audible alerts

Package Includes

• 1 x MB27F - 27mm Flat Loud Continuous Buzzer
