DS18B20 Temperature Sensor Adapter Module

The DS18B20 Temperature Sensor Adapter Module is a compact interface board designed for easy connection of DS18B20 digital temperature sensors to microcontrollers and development boards. It provides a screw terminal input for secure sensor wiring and a standard 3-pin header output for quick integration with Arduino, ESP32, Raspberry Pi, and other embedded systems. The onboard pull-up resistor ensures stable 1-Wire communication for accurate temperature sensing applications.

Technical Specifications:

• Sensor Compatibility: DS18B20 Digital Temperature Sensor
• Communication Protocol: 1-Wire Interface
• Operating Voltage: 3.0V to 5.5V DC
• Interface Pins: DAT, VCC, GND
• Onboard Pull-up Resistor: 4.7KΩ
• Connector Type: Screw Terminal + 3-Pin Header
• PCB Material: FR4
• Mounting Holes: Dual mounting holes for secure installation
• Board Color: Black
• Signal Type: Digital Output

Features:

• Easy DS18B20 sensor interfacing
• Built-in pull-up resistor for stable communication
• Screw terminal for reliable wire connection
• Compact and lightweight design
• Compatible with 3.3V and 5V systems
• Standard header pins for breadboard use
• Suitable for long-distance sensor wiring
• Simple integration with microcontrollers
