Description
This is a combination of 4 input two NOR gates are monolithic complementary MOS (CMOS) integrated circuits. The N-channel and P-channel enhancement mode transistors provide a symmetrical circuit with output swings essentially equal to the supply voltage. This results in high noise immunity over a wide supply voltage range.
Technical Specification:
- Max Processing Temp: 260
- Maximum Operating Supply Voltage: 18 V
- Maximum Propagation Delay Time @ Maximum CL: 250@5V|120@10V|90@15V ns
- Maximum Quiescent Current: 5 uA
- Minimum Operating Supply Voltage: 3 V
- Mounting: Surface Mount
- MSL Level: MSL 1 – Unlimited
- Operating Temperature: -55 to 125 °C
- Pin Count: 14
- Product Dimensions: 8.75 x 4 x 1.5 mm
- Supplier Package: SOIC
- Typical Quiescent Current: 0.02 uA
Features:
- Two Independent 4-input NOR Gates
- Standard CD4002 Pin Configuration
- Wide Operating Voltage Range
- Operating Temperature to 85°C
- Low Power CMOS
Applications:
- Automotive
- Alarm system
- Data terminals
- Industrial controls
- Instrumentation
- Remote metering
- Medical Electronics
- Computers
