BMP180 Barometric Pressure Sensor Module

SKU: VM00486

Price:
Sale price Rs. 42.37 (excl.18% GST)
Rs. 50.00

Description

BMP180 is one of sensor of BMP XXX series. They are all designed to measure Barometric Pressure or Atmospheric pressure. BMP180 is a high precision sensor designed for consumer applications. Barometric Pressure is nothing but weight of air applied on everything. The air has weight and wherever there is air its pressure is felt. BMP180 sensor senses that pressure and provides that information in digital output.

 Technical Specification:

  • Operating  voltage of  BMP180: 1.3V – 3.6V
  • Input voltage of  BMP180MODULE: 3.3V to 5.5V
  • Peak current : 1000uA
  • Consumes 0.1uA standby
  • Maximum voltage at SDA , SCL : VCC + 0.3V
  • Operating temperature: -40ºC to +80ºC
  • Pressure range: 300 to 1100hPa
  • Pressure conversion time: 5msec

Features:

  • Can work on low voltages
  • 4Mhz I2C interface
  • Low power consumption (3uA)
  • Potable size
  • Can measure temperature and altitude

Applications:

  • Indoor navigation
  • Sport devices
  • Computer Peripherals
  • GPS
  • Weather forecast
  • Vertical velocity Indication
  • Hobby projects
