7Semi 3-Phase TMC6300 BLDC PMSM Brushless Motor Driver Breakout

The 7Semi TMC6300 3-Phase Brushless Motor Driver Breakout is a compact and efficient driver module designed for 3-phase BLDC and PMSM motors. It uses the TMC6300 driver IC, which integrates three half-bridges for full 3-phase motor control. With its low-voltage operation, high efficiency, and small form factor, this breakout is ideal for battery-powered systems, robotics, drones, gimbals, small pumps, fans, toys, and embedded motor control applications.

Technical Specifications:

• Driver IC: TMC6300

• Motor Type: 3-phase BLDC or PMSM

• Supply Voltage (VM): 2V to 11V DC

• Output Current: Up to 2A peak (approx. 1.4A RMS)

• Control Interface: 6 PWM/digital inputs (high-side + low-side for U, V, W phases)

• Additional Pins: Fault/diagnostic output, standby/enable input

• Efficiency: Low RDS(on) MOSFET-based half bridges

• Standby Current: Extremely low, suitable for always-on systems

• Protection: Integrated thermal shutdown, short-circuit protection

Features:

• Full 3-phase MOSFET driver for BLDC/PMSM motors

• Works on very low voltage (2–11V), ideal for small battery packs

• High efficiency with integrated charge pump and low RDS(on) MOSFETs

• Supports block, trapezoidal, or sine-wave commutation depending on control method

• Low standby current for battery-powered devices

• Built-in protection features for safe operation

• Compact breakout board suitable for breadboards and embedded applications

Applications:

• Small robots, UAVs, drones, and BLDC-based mechanisms

• Camera gimbals, stabilizers, and pan/tilt brushless systems

• Battery-powered mini fans, pumps, and blowers

• Consumer devices and portable electronic products

• DIY BLDC motor projects and brushless hobby builds

• Educational and prototyping uses for 3-phase motor control

• Compact automation modules and embedded BLDC motor systems
