Description
Special components called resistors are made for the express purpose of creating a precise quantity of resistance for insertion into a circuit. Resistors have two leads, there is no polarity for a resistor and hence can be connected in both directions.
Technical Specification:
- Resistor type: Metal Film
- Resistance: 470KΩ
- Tolerance: 1%
- Power Rating: 1/4W
Features:
- Automatically insertable
- High quality performance
- Non - Flame type available
- Too low or too high can be supplied on a case to case basis
- Cost effective and commonly used
Color Band Details:
Applications:
- Current limiters
- Shunt measure
- Heaters
- Strain gauges
- Potential dividers
- To create voltage drop
