Description
The DC Motor Speed Controller allows controlling direction of a DC motor .
Technical Specification:
- PWM frequency: -13kHz
- The operation environment temperature: -20-40℃
- Working Voltage: DC 12V – DC 40V
- Control Power:0.01 – 400W
- Static Current:0.02 A ( Standby )
- PWM Duty Cycle:10% -100%
- Size: 60mm*55mm*30mm(L*W*H)
Features:
- Control the speed of a DC motor with this controller
- High efficiency, high torque, low heat generating
- With reverse polarity protection, high current protection
- Control voltage over-voltage protection function
- The overload and short circuit protecting current is 10A
Applications:
- Hobby Projects
- DC motor control
- For Controlling Automotive Cooling Fan Speed, Auto Fan Speed, Windshield Wipers, Auto Air Conditioning
